Name: IY1 4-Inch Y128 Lithium Niobate (LN) Wafer, 500 µm, SAW Grade
SKU: IY1
Availability: InStock

Price range: $140.00 through $1,708.00

Size

Clear

SKU: IY1 Category: Substrates & Conductive Materials

4-Inch Y128 Lithium Niobate (LN) Wafer, 500 µm, SAW Grade

4-inch Y128 lithium niobate LN wafer 500 micrometer SAW grade

This 4-inch lithium niobate (LiNbO₃ / LN) wafer features a
Y128 orientation and a nominal thickness of 500 µm.
It is supplied as a SAW-grade substrate for research,
fabrication and development of surface acoustic wave devices
and related piezoelectric applications.

Product Specifications

Product Type	Lithium niobate wafer
Material	Lithium Niobate (LiNbO₃ / LN)
Wafer Diameter	4 inch
Crystal Orientation	Y128
Thickness	500 µm
Grade	SAW Grade
Primary Application	Surface Acoustic Wave (SAW) device research and fabrication

Available Model

Diameter	Orientation	Thickness	Grade	Suggested SKU
4 Inch	Y128	500 µm	SAW Grade	LN-Y128-4IN-500UM

Key Features

Lithium niobate (LiNbO₃) crystalline substrate
4-inch wafer format
Y128 crystal orientation
Nominal wafer thickness of 500 µm
SAW-grade substrate for acoustic-wave device applications
Suitable for laboratory research and device fabrication

Typical Applications

Surface Acoustic Wave (SAW) devices
Acoustic wave sensor research
Piezoelectric device research
Microfabrication and thin-film processing
RF and acoustic device development
University and laboratory research

Important:
Please confirm the required crystal orientation, wafer thickness,
surface finish, dimensional tolerance and other technical
specifications before ordering. Specifications not explicitly
stated should be confirmed prior to purchase.

Size	4-Inch DSP X-Cut, 4-Inch DSP X-Cut (Optical Grade), 4-Inch DSP Y-128 DEG Cut, 4-Inch DSP Y-41 DEG Cut, 4-Inch DSP Y-Cut, 4-Inch DSP Z-Cut, 4-Inch DSP Z-Cut (Optical Grade), 4-Inch SSP X-Cut, 4-Inch SSP Y-128 DEG Cut, 4-Inch SSP Y-Cut, 4-Inch SSP Z-Cut, Y128 Black Wafer
